Strong, even when the going gets tough – powerful down to the depths
Drilling rig for depths of 150 to 200 metres
The ADLER B 150 is the compact counterpart to the B 200 – designed for drilling work in confined spaces. With a width of just 130 cm and a weight starting at 9 t, the drilling rig can reach even hard-to-access sites via narrow paths, for example at existing buildings.
Despite its compact dimensions, the B 150 is capable of drilling to depths of up to 200 m. A key advantage is that the rig can often be driven directly to the site, thereby avoiding the time-consuming and costly need to use a crane to hoist the drilling rig into position.
Downloads
Advantages
- Powerful drilling rig, from 9 t
- Only 130 cm wide
- Single-drill-head drive with torques of up to 9,800 Nm
- Retraction force 95 kN / drill string 4 m or 2 x 2 m
- Fitted as standard with 500 mm mast lowering
- Easy to operate via remote control
- Optional accessories such as a generator
- Output 15.1 kVA, high-pressure cleaner and much more.
Application
- Well drilling
- Geothermal well drilling
- Geological exploratory drilling and much more
Technical specifications
| Drive unit Deutz-Motor | 4 cyl. / 110 kW at 2.000 U/min / 150 hp siesel (emission level 5) |
| Tank capacity | 150 l |
| ADLER Crawler chassis F 75 | Width: 1.300/1.700 mm Length: 2.523 mm |
| Support legs | 2 x front extendable into the drilling axis / 2 x rear fixed |
| Drill rods | 2 x 2 m oder 4 m |
| Feed length | 4,4 m |
| Feed | 55 kN |
| Retraction force | 95 kN |
| Mast lowering 500 mm | as standard |
| Feed system | via hydraulic cylinder |
| Drilling drive | Laterally adjustable by 600 mm |
| Single-drill head, top (drill pipe) | |
| EURO DRILL Bohrkopf unten (Schutzrohr) | |
| Torque / speed | M1 = 9.800 Nm n1 = 36 (48) rpm M2 = 6.400 Nm n2 = 55 (73) rpm M3 = 4.900 Nm n3 = 72 (96) rpm M4 = 3.200 Nm n4 = 110 (146) rpm |
| Operating pressure / Flow rate: | 250 bar / 90 (129) l/min |
| Free passage | 95 mm |
| Double drill head, bottom (casing) | |
| Torque / speed | up to 20.000 Nm / 44 rpm |
| Operating pressure / Flow rate | 270 bar / 100 rpm |
| Flushing passage | 150 mm (without protective tube) |
| Other speeds and torques possible | |
| Drill head | tiltable 45° |
| Clamping head | Passage 178 mm / 6 clamping claws |
| Flushing pump | max. 120 m³/h or max.12 bar |
| Clamp-break lifting clamp / clamping force / stroke / lifting force / torque | clamping range 219 mm / clamping force 245 kN stroke 400 mm / lifting force 198 kN / breakaway torque 18 kNm |
| Bottom clamp | max. clamping range 324 mm / clamping force 58 kN |
| Hydraulic rope winch | max. lifting force 10 kN / max. rope speed 50 m/min Rope diamete 9 mm / max. rope length 75 m |
| Mast extension | Hook load 15 kN / extension 835 mm Distance from center 700 mm |
| Wired remote control for driving and drilling | as standard |
| Transport dimensions L / W / H (depending on the equipment) | 8.212 mm / 1.300 mm / 2.875 mm (je nach Ausrüstung) |
| Weight of basic machine | from 9 t |
Drill rig B 150
